Deflector | Brass UNS-28000 |
Bulb | Glass with Glycerin SolutionJOB G5 or Day-impex-937 |
Load Screw | Brass UNS-28000 |
Seal | Brass UNS-28000 |
Frame | Brass UNS-28000 |
Seal Washer | Washer, Coated on Both Sides, And Applied with Teflon Tape |
Bulb Nominal DIA | Standard Response 5.0mm |
K Factor gpm/(psi)½( L³/min(bar)½ ) | 5.6 (80) |
Nominal Thread Size | 1/2” NPT and 1/2” BSPT |
Max. Working Pressure | 175 PSI (12bar) |
Factory Testing Pressure | 500 PSI (35bar) |
Min. Operating Pressure | 7 PSI (0.5 bar) |
Temp. Rating ℉ (℃) | 135(57) 155(68) 175(79) 200(93)286(141) |
Finish | Brass or Chrome Plated or White Plated Available |
